GOODMAN 3 TON 15.2 SEER2 AC & 80% AFUE 60K BTU GAS FURNACE SYSTEM - UPFLOW
The Goodman 3 Ton 15.2 SEER2 AC & 80% AFUE 60K BTU Gas Furnace System - Upflow, R32 (Model: GLXS4BA3610) combines an efficient 15.2 SEER2 air conditioner with an 80% AFUE gas furnace for optimal cooling and heating performance, designed for upflow installations. Its advanced features provide year-round comfort and energy savings.
Air Conditioner Features:
- Energy-Efficient Compressor: Optimized for reduced energy consumption.
- Pre-Charged for 15 Tubing: Simplifies installation.
- Enhanced Heat Exchange: Copper tube and aluminum fin coil for improved thermal efficiency.
- Durable Design: Features filter drier, high-pressure switches, and long-life capacitors.
- Certifications: AHRI Certified and ETL Listed.
Cabinet Features:
- Grille-Style Top Design: Compliant with UL 60335-2-40.
- Powder-Coated Finish: Attractive gray finish with 500-hour salt-spray approval.
- Hurricane-Ready: Meets 2023 Florida Building Code when anchored (anchor brackets available).
- Easy Maintenance: Single-panel access for controls and accessories.
- Multi-Position Installation: Supports upflow, horizontal left, or right configurations.
- Flexible Venting: Works with direct vent (2-pipe) or non-direct vent (1-pipe) options.
Evaporator Coil - CAPTA3626B3:
- All-Aluminum Build: Corrosion-resistant and durable.
- Optimized for R-32 Refrigerant: Includes circuits, manifolds, and R-32 sensor for efficient operation.
- Compact Design: 21 depth for easy attic installation.
- Efficient Drain Pan: UV and rust-resistant thermoplastic with low water retention.
Gas Furnace - GR9S800603BN:
- 80% AFUE Rating: Reliable and cost-effective heating.
- Low NOx Emissions: Environmentally friendly with reduced emissions.
- Quiet Operation: Energy-efficient and quiet heating.
- Tax Credit Eligible: Meets energy efficiency standards for incentives.
The Goodman 3 Ton 15.2 SEER2 AC & 80% AFUE 60K BTU Gas Furnace System delivers efficient, reliable heating and cooling in a durable and flexible design, ideal for homeowners seeking long-term comfort and savings.
Specifications:
AC Model Number: GLXS4BA3610
SEER: 14.3
Tonnage: 3
Unit Height x Width x Depth: 39.5 x 29 x 29 in
Unit Weight: 158 lb
Cooling Capacity Nominal: 36,000 Btu/HR
Power Voltage: 208/230 V
Phase: Single
Motor Type: PSC
Min Circuit Amps: 17.75
Max Fuse Size: 30
Liquid Connection: 3/8
Suction Fitting: 7/8
Refrigerant Type: R-32
Evaporator Coil Model Number: CAPTA3626B3
Evaporator Coil Tonnage: 3
Evaporator Coil Height x Width x Depth: 26 x 17.5 x 21 in
Evaporator Coil Unit Weight: 48 lb
Evaporator Coil Liquid Connection: 3/8
Evaporator Coil Suction Fitting: 7/8
Evaporator Coil Configuration: Upflow/Downflow
Evaporator Coil Metering Device: TXV
Evaporator Coil Refrigerant Type: R-32
Gas Furnace Model Number: GR9S800603BN
Gas Furnace Height x Width x Depth: 33-3/8 x 17.5 x 28 in
Gas Furnace Weight: 100 lb
Gas Furnace AFUE: 80%
Gas Furnace Configuration: Upflow/Horizontal
Gas Furnace BtuH Input: 60,000
Gas Furnace BtuH Output: 48,000
Gas Furnace Tons: 3
Gas Furnace CFM: 1,200
Gas Furnace Min. Circuit Amps: 7.7
Gas Furnace Motor Type: ECM
Gas Furnace Stages: Single
Gas Furnace LoNox: No
